Tabletop Round Bottle Capture Device

LabelOn™ Mini Synergy – Round BCD

Accurately place 100% Wrap Labels or Front and Back Labels.

Economical in-line small footprint 100%* wrap or Front and Back labeler for straight sided round bottles.

Mini Round Bottle Capture Device

Small Labeling Machine Features:

  • A Bottle/Jar Drive Roller and a Bottle/Jar Capture Device combine to hold the product millimeters from where the label is released for the complete length of the label(s) release. This allows for unmatched label alignment of the leading and trailing edges of the label.
  • 1 or 2 labels (with Programmable Separation) per product
  • Up to 100% Wrap Around Label (* or More ; example Tribe QR code labels)
  • Color Touch Screen Controls
  • Speed Synchronization
  • Adjustable Height of Label Placement
  • Labeling Accuracy ¹/₁₆ “

Machine Specifications:

  • Nominal Footprint size (L) 40 ” (W) 49 ” (H) 26 ”
  • Bottle/Jar Body height of 1 ” to 6 ” tall
  • Bottle Diameter ¹³/₁₆” to 4 ” (Standard)
  • Label Web of 0.75” to 5.9” (the Backing for the label should be between 1.0” to 6.0”)
  • Labeling accuracy +/- ¹/₁₆ ”
  • Label Roll Core 3 ” (inner diameter)
  • Label Roll Capacity 15 ” (outer diameter) – That’s Huge Label Web of 0.75” to 5.9” (the Backing for the label should be between 1.0” to 6.0”)!!
  • Power Single Phase 110v 50/60Hz – 800W
  • Machine Requires a Clean Air Supply; 2.20 CFM at 90 PSI
  • Label Head stepper motor
  • SUS#304 stainless steel and anodized aluminum construction

Labeling Equipment Function:
  • Round BCD – Accurately place 100% Wrap Labels or Front and Back Labels
Tabletop Round Wrap Labeler

Optional Accessories:

  • Hot Foil Coder for in-line Date or Batch codes
  • Overhead Conveyor Belt for Flat Sided Labeling
  • Transparent label sensor for clear labels
  • Taller Label Head
  • Wider Conveyor

At LabelOn™ we have listened to the market very carefully. Small Labeling Machines need to operate like our Larger Labelling machines.

The Mini Labeling machines need to get out a good level of production volume, accurately and (*importantly*) with the ease of set up found on our bigger LabelOn™ Basic labeling machines.

Our Small Labelling Machines have Touch panel controls and Synchronized Motor Speeds.

When you have Mini Labelling Machines with the features we have packed into our Bottle Labelling Machines you have Labelling Machines that require a much lower *operator skill set * than the skill set required to operate Small Labelling Machines that fail to include the features of the LabelOn™ Mini Synergy Range of Small Labeling Machines.
